CMWS-4精密复合筛管是金属网布筛管和绕丝筛管的结合体，由2层金属过滤网、2层支撑泄流网和1层绕丝层组成，双重过滤体系具备优异的防砂性能和耐 冲蚀性能，适用于热采井、高产井、严重腐蚀等条件苛刻的环境。

主要特性

◎ 金属网过滤层和绕丝过滤层提供双重过滤体系，具有良好的挡砂能力；

◎ 316L不锈钢金属丝编织网过滤结构，防砂可靠性高，抗破坏能力强；

 ◎ 支撑泄流网设置，有效改善流体的流动特性，总体流通性好；

◎ 渗透率高，孔隙度高，有效过流面积大；

 ◎ 耐酸碱腐蚀、耐高温、抗冲蚀；

◎ 强度高、抗变形能力强，直径方向变形40%后，防砂性能仍然完好；

◎ 挡砂精度高，可提供60~300μm精度范围的产品。

适用范围

◎ 出砂中等或严重

◎ 中细砂或粉细砂防砂

◎ 中高泥质含量稠油或稀油

◎ 高温高压井、热采井、腐蚀性油气井

产品应用

◎ 出砂中等或严重；

◎ 中细砂或粉细砂防砂；

◎ 中高泥质含量稠油或稀油；

◎ 高温高压井、热采井、腐蚀性油气井。

CMWS-4 PRECISION COMPOSITE SCREEN

The CMWS-4 precision composite screen is a combination of metal mesh screen and a wirewrapped screen. It is composed of 2 layers of metal filter screens, 2 drainage layers, and 1 layer  of wire-wrapped layers. The dual filtration system has excellent sand control performance and  erosion resistance. It is suitable for harsh environments such as thermal production wells, highyield wells and severe corrosion.

FEATURES

◎ Metal mesh filter layer and wire-wrapped filter layer provide dual filter system with good sand  control ability;

◎ 316L stainless steel wire woven mesh filter structure, high sand control reliability, strong damage  resistance;

◎ The setting of supporting drainage network can effectively improve the flow characteristics of  fluid, and the overall flow ability is good;

◎ High permeability, high porosity, large effective flow area;

◎ Acid and alkali resistance, high temperature resistance and erosion resistance;

◎ High strength, strong deformation resistance, 40% deformation in diameter direction, sand  control performance remains unchanged;

◎ High precision sand control, can provide 60μm~300μm filtration rating range of products.
