CS-BF型坐落接头是一种顶部不通或者选择性通过的坐落接 头，能够与多种钢丝作业工具及流量控制工具配合。CS-BR型坐落 接头是一种底部不通的坐落接头。在方案设计时需要充分考虑坐落 接头的位置、数量和形式，便于配合流量控制工具的使用。

主要特性

◎ 密封功能，抛光密封筒能与密封件形成有效的密封；

◎ 完整的锁定沟槽；

◎ 外径与油管接箍外径相同，材质相同；

◎ 采用API标准螺纹。

应用

◎ 用于坐放盲堵，用于关井或油管测试；

◎ 用于坐放速度式安全阀、平衡止回阀、旁通循环阀；

◎ 坐放测试工具，如压力温度计等。

CS-BF/CS-BR LANDING NIPPLE

INTRODUCTION

CS-BF Type Landing Nipple is a top no-go or selective landing  nipple that provides for the location of various wireline flow control  devices in the production string. The Model CS-BR Landing nipple  is a bottom no-go landing nipple that provides for the location of  various wireline flow control devices in the production string. The location and number of landing nipples should be carefully  considered in the completion planning stages to allow maximum  versatility in the positioning of various flow control accessories.

FEATURES

◎ Seal bore - contoured and polished to guarantee effective seal;

◎ Integral locking groove;

◎ OD and material same as that of tubing coupling;

◎ Available in API and premium threads.

APPLICATION

◎ Land blanking plugs to shut in well or to test the production tubing;

◎ Land velocity type safety valves, equalizing check valves, circulating  blanking plugs;

◎ Land instrument hangers with geophysical devices like pressure and  Tempature recorders;

◎ Prevent loss of wireline work string in some cases.

Note: Other specification products are available.
