热采悬挂密封器主要用于稠油热采井蒸汽吞吐或热采井的堵水作业工艺，密封油套环空，防止注入蒸汽上窜到密封器以上的油套环空中，另外密封器能牢靠的悬挂于井下，对下部的染管柱起到悬挂和支撑的作用。

主要特性

◎ 双重密封设计，密封可靠；

◎ 耐高温350℃，工作压差20MPa；

◎ 密封性能不受温度交替变化影响；

◎ 具有丢手功能；

◎ 长期处于高温下的密封性能可靠；

◎ 配合热采井下开关使用，形成防污染热采管柱；

◎ 可作为热采桥塞，封堵底水；

◎ 下工具打捞，旋转上提解封，解封可靠

主要优点

◎ 耐高温高压性能好

◎ 密封、锚定、解封性能可靠；

◎ 可长期放置于井内；

◎ 密封性能不受温度交替变化影响

HANGING PACKER

INTRODUCTION

The hanging packer is used in CSS and water shutoff operation in thermal recovery wells. It can seal the annulus preventing the steam from getting to the annulus above the packer. Besides, the packer can hang firmly in the wellbore so it can also be used for hanging or supporting the anti-pollution string.

FEATURES

◎ Dual sealing design, sealing reliable;

◎ Temperature rating 350℃ , working pressure rating 20MPa;

◎ Sealing performance independent of temperature change on alternate;

◎ With release function;

◎ Reliable long-term sealing performance at high temperature;

◎ Anti-pollution string can be formed when the tool incorporating with underground switch;

◎ Can be used as a bridge plug for thermal recovery.

BENEFITS

◎ Good performance of high-pressure and high-temperature;

◎ With reliable performance of sealing, anchoring and releasing;

◎ Can be placed in the well for long-term;

◎ Sealing performance is unaffected by temperature alternately changes.

Note: Other specification products are available.
